Configuring KONTAKT's Outputs Section
- Load an instance of KONTAKT, and enable Outputs in the Workspace menu to make the Outputs area visible at the bottom of KONTAKT's interface.
- The Outputs section is now displayed in the lower half of the Rack space.
Click the '+' button to display the Outputs options dialog.
- This menu is used to create additional KONTAKT output channels.
- Quantity sets the number of KONTAKT output channels you want to add.
Click the Quantity field and drag the mouse cursor up or down. - Number of channels lets you choose the channel configuration for all new KONTAKT Outputs (e.g. 1 for mono, or 2 for stereo).
In our example, we want to route KONTAKT presets to 16 stereo output channels, so we choose a Quantity of 16 and set the Number of channels to 2.
- Quantity sets the number of KONTAKT output channels you want to add.
- In the Soundcard / Host output drop-down menu, select st. 1 [1].
- Ascending output assignment (assigns each new channel to the next available outputs).
- Delete existing channels before creating new ones (create all new output channels).
- (Optional) Make this your default configuration (saves setup for future DAW projects).
- Click OK to confirm. Finish by ticking these remaining boxes:
Now that you have the 16 channels available, you can load Bogren Digital Instrument:
- Click on 'Mixer' and assign all channels:
Note: When you route channels, they no longer go through the 'Master channel':
